Client Type
Renewable Developer
Location
California, USA
Discipline
Solar Photovoltaic System
Codes Applied
ASCE 7, IBC, AISC
Client Confidentiality
Due to client NDA commitments, the showcased projects represent only a portion of our work and not the full scope of what we've delivered.
Challenge
The brief, and the constraint.
The client needed structural verification for a commercial PV field, including racking, wind uplift, foundation reactions and cable-routing coordination before permitting.
Approach
How we engineered it.
We checked PV racking reactions against ASCE 7 wind cases, reviewed pile/foundation capacity, coordinated inverter pad layouts, and issued permit-ready structural markups with load summaries.
Result
What shipped.
Foundation loads were verified and the PV package moved into permitting with a clean structural basis, avoiding late racking redesign during procurement.
Foundation loads verified
Permit package supported
Racking redesign avoided
Gallery
Drawings & renders.
Deliverables
- Structural vetting report
- Foundation reaction summary
- PV racking markups
- Wind load checks
- Permit support package
- Compliance summary
Tools & Codes
STAAD.ProAutoCADPVsystASCE 7IBCAISC
“Solar structures look repetitive until wind uplift finds the weak support line. We verify racking and foundation reactions before procurement locks the site into an expensive redesign.”- Lead Engineer, Fluxiss
